Kubernetes Cluster on Ubuntu 20.04 Made Easy

Hey guys! So, you’re looking to dive into the awesome world of Kubernetes and want to get a cluster up and running on good ol’ Ubuntu 20.04? You’ve come to the right place! Setting up your own Kubernetes cluster might sound like a big, scary task, but trust me, with a little guidance, it’s totally doable. We’re going to walk through this step-by-step, making sure you understand why we’re doing each part. By the end of this, you’ll have your very own playground to experiment with container orchestration. Pretty cool, right?

Why Build Your Own Kubernetes Cluster?

Before we jump into the nitty-gritty, let’s chat about why you might want to build your own Kubernetes cluster on Ubuntu 20.04. Sure, there are managed services out there, but doing it yourself gives you a deeper understanding of how Kubernetes actually works. You’ll learn about networking, control plane components, worker nodes, and how they all play together. This knowledge is invaluable for troubleshooting, optimizing, and really mastering Kubernetes. Plus, it’s a fantastic way to learn without incurring cloud costs, especially when you’re just starting out or experimenting with new ideas. Think of it as your own personal, hands-on lab. We’re going to focus on using kubeadm , which is the official tool for bootstrapping a Kubernetes cluster. It simplifies a lot of the complex setup that used to be a real headache. So, grab your favorite beverage, get comfortable, and let’s get this cluster built!

Prerequisites: What You’ll Need

Alright, before we start slinging commands, let’s make sure you’ve got everything ready. Think of this as your pre-flight checklist. For this guide, we’ll assume you’re setting up a basic two-node cluster: one control plane node (where the brains of the operation live) and one worker node (where your actual applications will run). You can always add more worker nodes later, but this is a great starting point. You’ll need at least two Ubuntu 20.04 servers (virtual machines or physical machines, doesn’t matter). These servers should have a minimum of 2GB of RAM and 2 CPUs each . More is always better, especially for the control plane if you plan on running heavier workloads, but 2GB/2CPUs is the bare minimum to get things moving. Make sure they have static IP addresses . This is super important for Kubernetes to communicate reliably. If your IPs are dynamic and change, your cluster will likely break. Also, ensure SSH access to all your nodes with a user that has sudo privileges. We’ll be running commands that require root access. Finally, and this is a big one, you need to disable swap on all nodes. Kubernetes doesn’t play nicely with swap enabled, as it can cause performance issues and unexpected behavior. We’ll show you how to do that. Oh, and a stable internet connection is a must for downloading necessary packages. Got all that? Awesome, let’s move on!

Step 1: Preparing Your Nodes

Okay, let’s get our hands dirty with the actual setup. Preparing your nodes is a crucial first step for any successful Kubernetes deployment. We need to make sure all our machines are configured correctly before we even think about installing Kubernetes. This involves a few key actions that ensure stability and prevent common issues down the line. First up, we need to update our package lists and upgrade any existing packages. This is standard practice for any Linux server setup. Open up an SSH session to each of your Ubuntu 20.04 machines and run:

sudo apt update && sudo apt upgrade -y

This ensures you’re running the latest software versions available for your distribution. Next, we absolutely must disable swap . As I mentioned earlier, Kubernetes really dislikes swap being enabled. It can lead to performance degradation and unpredictable application behavior. To disable swap for the current session, run:

sudo swapoff -a

But that’s not enough! Swap will likely be re-enabled after a reboot. To make this change permanent, you need to edit the /etc/fstab file. Open it with your favorite text editor (like nano or vim ):

sudo nano /etc/fstab

Find the line that refers to swap (it will likely contain the word swap ) and comment it out by adding a # at the beginning of the line. It should look something like this:

# /swap.img      none    swap    sw      0       0

Save the file and exit. Now, let’s configure some essential kernel modules and settings. Kubernetes networking relies on certain kernel modules being loaded and network parameters being set correctly. We need to ensure the br_netfilter module is loaded, which is necessary for bridging network traffic. We also need to configure sysctl parameters to enable IP forwarding and set bridge network filter settings. Create a new sysctl configuration file:

sudo nano /etc/sysctl.d/kubernetes.conf

Add the following lines to this file:

net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
vm.swappiness = 0

vm.swappiness = 0 reinforces disabling swap, ensuring the system prioritizes RAM. Then, apply these changes without rebooting:

sudo sysctl --system

Finally, we need to install containerd , which is the container runtime that Kubernetes will use. Docker is also an option, but containerd is often preferred for its simplicity and integration. Let’s install it:

sudo apt install -y containerd

After installation, you need to configure containerd. Create its default configuration file:

sudo mkdir -p /etc/containerd
sudo containerd config default | sudo tee /etc/containerd/config.toml

Now, edit the configuration file to ensure the systemd cgroup driver is used. This is important for Kubernetes to manage container resources properly. Open the file:

sudo nano /etc/containerd/config.toml

Find the [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options] section and make sure SystemdCgroup is set to true :

[plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
  SystemdCgroup = true

Save and close the file. Then, restart the containerd service to apply the changes:

sudo systemctl restart containerd

And enable it to start on boot:

sudo systemctl enable containerd

Phew! That was a lot, but these steps are critical for a stable Kubernetes environment. Make sure you perform all these on both your control plane and worker nodes.

Step 2: Installing kubeadm, kubelet, and kubectl

With our nodes prepped and ready to go, it’s time to install the core Kubernetes components: kubeadm , kubelet , and kubectl . These are the tools that will allow us to initialize, manage, and interact with our cluster. We’ll be using kubeadm to bootstrap the cluster, kubelet to run on each node and manage pods, and kubectl on your local machine (or the control plane node) to send commands to the cluster. First, let’s set up the Kubernetes package repository so apt knows where to find the latest versions. Run these commands on all your nodes (control plane and worker):

# Install dependencies
sudo apt update
sudo apt install -y apt-transport-https curl

# Download Google Cloud public signing key
curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -

# Add the Kubernetes apt repository
echo "deb https://apt.kubernetes.io/ kubernetes-xenial main" | sudo tee /etc/apt/sources.list.d/kubernetes.list

Now that the repository is added, we need to update our package list again to include the Kubernetes packages:

sudo apt update

It’s crucial to pin the versions of kubeadm , kubelet , and kubectl to avoid unexpected upgrades that might break compatibility. We want to use the specific versions that work together. Let’s install them, and also make sure they are held back from automatic upgrades:

sudo apt install -y kubelet kubeadm kubectl
sudo apt-mark hold kubelet kubeadm kubectl

The apt-mark hold command tells apt not to automatically upgrade these packages. This is a good practice when setting up specific versions of critical software. Now, let’s verify the installation by checking the versions:

kubeadm version

You should see the version number printed. If you encounter any issues, double-check the previous steps, especially the repository configuration and package installation. Remember, consistency across all nodes is key here. If you want to install a specific version (e.g., 1.28.0-00 ), you would modify the install command like so: sudo apt install -y kubelet=1.28.0-00 kubeadm=1.28.0-00 kubectl=1.28.0-00 .

Step 3: Initializing the Control Plane Node

Alright, this is where the magic happens! We’re going to initialize the control plane node using kubeadm . This command will set up all the necessary components for the Kubernetes control plane, like the API server, etcd (the cluster’s database), scheduler, and controller manager. This is the brain of your Kubernetes cluster. Make sure you’re running these commands on the machine designated as your control plane node . Let’s start by running:

sudo kubeadm init --pod-network-cidr=10.244.0.0/16

Let’s break down this command: sudo kubeadm init is the core command. The --pod-network-cidr=10.244.0.0/16 flag is extremely important . It tells Kubernetes which IP address range will be used for your pods. This CIDR block must be compatible with the network plugin you choose later. 10.244.0.0/16 is commonly used with the Flannel network plugin, which we’ll likely use. If you choose a different network plugin, you might need to adjust this CIDR accordingly. This command can take a few minutes to complete as kubeadm downloads container images and configures the control plane components. Once it’s done, you’ll see a lot of output, including some crucial information at the end.

Pay close attention to the instructions for setting up kubectl for a non-root user. It will tell you to run commands like these:

mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

These commands copy the admin configuration file to your user’s home directory, allowing you to interact with the cluster using kubectl without needing sudo for every command. If you’re logged in as the ubuntu user, these are the commands you’ll use. You can verify that kubectl is working by running:

kubectl cluster-info

If everything is set up correctly, you should see information about your Kubernetes control plane. The output of kubeadm init also provides the join command for your worker nodes. It will look something like this:

kubeadm join <control-plane-ip>:6443 --token <some-token>
    --discovery-token-ca-cert-hash sha256:<some-hash>

Do not lose this command! Copy it and save it somewhere safe. You’ll need it in the next step to connect your worker node(s) to the control plane. If you accidentally close the terminal or lose the join command, don’t worry. You can regenerate a token and its hash on the control plane node using these commands:

# To create a new token (valid for 24 hours by default)
sudo kubeadm token create --print-join-command

This will output the kubeadm join command you need. Remember to run sudo kubeadm init with the correct --pod-network-cidr that matches your chosen CNI plugin.

Step 4: Installing a Pod Network Add-on (CNI)

So, your control plane is initialized, which is awesome! But right now, your pods can’t communicate with each other. This is because Kubernetes needs a pod network add-on , often called a Container Network Interface (CNI) plugin, to enable pod-to-pod communication across different nodes. Without this, your applications won’t be able to talk to each other, which defeats a lot of the purpose of Kubernetes! There are several CNI plugins available, but Flannel is a popular, simple, and reliable choice for getting started. We’ll use Flannel for this guide. Make sure you are still on your control plane node to apply the Flannel configuration. The command is straightforward:

kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml

This command downloads the Flannel manifest file from its GitHub repository and applies it to your cluster using kubectl . Flannel will then deploy its own pods (usually as a DaemonSet) to each node, creating the necessary overlay network for your pods. It sets up the networking infrastructure that allows pods on different machines to reach each other seamlessly.

What’s happening here? Flannel essentially creates a virtual network that spans across all your nodes. It uses techniques like VXLAN encapsulation to tunnel network traffic between pods, regardless of which physical machine they are running on. This is a fundamental piece of Kubernetes networking that enables features like service discovery and load balancing across your cluster. You can monitor the deployment of Flannel pods by running:

kubectl get pods -n kube-system

You should see kube-flannel-ds-* pods running. It might take a minute or two for them to become fully ready. Once Flannel is running, your cluster’s networking is mostly set up. However, you’ll notice that your control plane node ( kubectl get nodes ) will show up as NotReady . This is because the control plane node won’t schedule pods (including application pods) onto itself until a CNI plugin is installed. After applying the Flannel manifest, the node status should change to Ready shortly.

If you decided to use a different Pod Network CIDR during kubeadm init , make sure you download the correct Flannel configuration that matches your CIDR. For example, if you used 192.168.0.0/16 , you would need to find a Flannel manifest that is configured for that range, or modify the default one. The official Flannel documentation is your best friend here if you deviate from the standard setup. Getting this network layer right is absolutely critical for a functional cluster, so take your time and ensure it’s applied correctly.

Step 5: Joining Your Worker Node(s) to the Cluster

We’ve got a control plane running and a network layer set up. Now it’s time to join your worker node(s) to the cluster . This is where you connect your other machines (the ones that will actually run your applications) to the control plane. Remember that kubeadm join command we saved earlier? This is what it’s for! If you don’t have it anymore, don’t sweat it – we showed you how to regenerate it on the control plane node. Ensure you are logged into your worker node via SSH for this step.

Execute the kubeadm join command that you copied from the control plane initialization output. It will look something like this:

sudo kubeadm join <control-plane-ip>:6443 --token <some-token>
    --discovery-token-ca-cert-hash sha256:<some-hash>

This command tells the worker node to connect to the specified control plane IP and port, authenticating using the provided token and certificate hash. The kubelet service on the worker node will then register itself with the control plane’s API server. It might take a minute or two for the worker node to fully join and be recognized by the cluster. You’ll see output indicating success or failure. If it fails, double-check the IP address, token, and hash, and ensure that network connectivity exists between your worker node and the control plane (firewalls can be a common culprit!).

Once the join command completes successfully, you can switch back to your control plane node and verify that the worker node has joined the cluster. Run the following command:

kubectl get nodes

You should now see both your control plane node and your worker node listed, with their status as Ready . If you have multiple worker nodes, repeat this join process for each one. The key is that the kubeadm join command is executed on the worker node , and it contains details about the control plane . This step essentially expands your cluster’s capacity, allowing you to deploy more applications and handle more load. It’s the process of scaling out your Kubernetes infrastructure. Congratulations, you’ve successfully added a worker node!

Verifying Your Cluster

To verify your cluster is working as expected, you can run a few more checks. From your control plane node (where you have kubectl configured), run:

kubectl get nodes -o wide

This command should list all your nodes (control plane and workers) with their internal and external IP addresses, OS image, kernel version, and container runtime version. Ensure all nodes show Ready status. You can also check the status of system pods:

kubectl get pods --all-namespaces

This command lists all pods running in the cluster, including those in the kube-system namespace (which are core Kubernetes components like kube-dns , etcd , coredns , and Flannel). All these pods should be in a Running state. To really test it out, you can deploy a simple application. Let’s deploy a basic Nginx web server:

kubectl create deployment nginx-test --image=nginx
kubectl expose deployment nginx-test --port=80 --type=NodePort

Wait a moment for the deployment and service to be created, then check the pods:

kubectl get pods

You should see an nginx-test pod running. Then check the service:

kubectl get services

Note the NodePort assigned to the nginx-test service (it will be a port in the range of 30000-32767). You can then access Nginx by opening a web browser and navigating to http://<any-node-ip>:<nodeport> . For example, if your control plane IP is 192.168.1.100 and the NodePort is 31234 , you’d go to http://192.168.1.100:31234 . You should see the default Nginx welcome page! This confirms that your applications can be deployed and accessed.

Conclusion: Your Kubernetes Journey Begins!

And there you have it, folks! You’ve successfully created your very own Kubernetes cluster on Ubuntu 20.04 using kubeadm . We’ve covered everything from preparing your nodes, installing the core components, initializing the control plane, setting up networking with Flannel, and joining your worker nodes. This hands-on experience is absolutely priceless for anyone looking to get serious about container orchestration. You’ve built a foundation that you can now expand upon. You can add more worker nodes, explore different CNI plugins, dive into advanced networking, and start deploying your own containerized applications with confidence. Remember, Kubernetes is a vast ecosystem, and this is just the beginning. Keep experimenting, keep learning, and don’t be afraid to break things and fix them – that’s how we all learn best. Happy orchestrating!
